Baldrick17

Baldrick17 Overview

The Baldrick17 is our newest pixel controller to join the Baldrick Family, designed for professional lighting displays and large-scale installations. With support for up to 750 pixels per port at 40fps and high refresh rates, it's perfect for creating stunning visual effects.

Baldrick17 Controller Features

• 5 ports accepting 5v - 48v with onboard power management and able to accept individual voltages (to avoid any BOOM BOOM BOOM BOOMS)
• Power ports are banked (4 + 4 + 4 + 4 + 1)
• 17 Ports handling up to 750 pixels per port at 40fps
• 17 fused connectors which combined with the included 7.5 amp fuses allows for full pixel runs at 100%
• DDP, Artnet, E1.31 & sACN compatible
• 3 Programmable Turniputs ports (Can use the FPP API to start / stop a sequence and full lamp control)
• No Pi or FPP Licence required
• Push from xLights integration

In addition, we've tried to add some simple quality of life improvements such as a QR code which links directly to the manual (easy to read on a mobile in the dark) and the three buttons have not only ports but physical buttons onboard to help you test without having to hook everything up.
